Transition Networks Smart Managed PoE+ Switch
Transition Networks Smart Managed PoE+ Switch

Transition Networks Smart Managed PoE+ Switch

Model: SM8TAT2SA-NART

Category: Enterprise Networking, Enterprise Hubs & Routers & Switches

Brand: Transition Networks

Dealer pricing

This switch is a next generation smart managed switch with 20Gbps switching capacity. It provides (8) 10/100/1000Base-T copper ports with IEEE 802.3at PoE+ capability and (2) additional 100/1000 dual speed SFP slots. The embedded Device Management System (DMS) provides the benefits of ease of use in the IP surveillance, wireless Access Point and other applications. The DMS capability built into the switches is new from Transition Networks and provides time-saving features enabling security integrators or network administrators to establish and document a baseline deployment, automatically discover and remotely configure attached IP-powered devices (PDs).

Main Features
  • IPv6 Access Management
  • Support Jumbo Frame up to 9K bytes
  • Authentication - RADIUS, TACACS+
  • DHCP Relay, DHCP Snooping, DHCP Server
  • L2/L3/L4 ACLs Support MAC ACL, IP standard/extended ACL
  • LLDP (Link Layer Discovery Protocol)
  • IEEE 802.3az Energy Efficiency
  • IP Source Guard, Port Security
  • Syslog

Brand Name Transition Networks
Category Type Enterprise Hubs & Routers & Switches
Depth 9.5", 1.7"
Environmental Certification RoHS, RoHS, WEEE, WEEE
Environmentally Friendly Yes
Ethernet Technology Gigabit Ethernet
Expansion Slot Type SFP
Form Factor Rack-mountable
Height 1.7"
Layer Supported 4
Limited Warranty Lifetime
Manageable Yes
Manufacturer Transition Networks, Inc
Model SM8TAT2SA-NA-RT, SM8TAT2SA-NART
Media Type Supported Optical Fiber, Optical Fiber, Twisted Pair, Twisted Pair
Modular Yes
Network Technology 10/100/1000Base-T, 1000Base-X, 10/100/1000Base-T, 1000Base-X
Number of +12V Rails 8, 2
Number of SFP Slots 2
Number of Total Expansion Slots 2
Packaged Quantity 4
Port/Expansion Slot Details 8 x Gigabit Ethernet Network, 2 x Gigabit Ethernet Expansion Slot, 8 x Gigabit Ethernet Network
Power Source Power Supply
Product Type Ethernet Switch, SFP
Redundant Power Supply Supported No
Shared SFP Slot No
Stack Port No
Total Number of Network Ports 8
Uplink Port No
Vendor Name Transition Networks
Weight (Approximate) 4.40 lb
Width 8.7"
