Planar VM55LX-X Digital Signage Display
Planar VM55LX-X Digital Signage Display

Planar VM55LX-X Digital Signage Display

Model: 997-9219-00

Category: Commercial Displays, Videowall Displays

Brand: Planar

Dealer pricing

The Planar® VM Series is a line of extreme and ultra-narrow bezel LCD displays that provide a video wall solution for demanding requirements of 24x7 mission-critical applications and high ambient light environments.

The Planar VM Series features 55" Full HD LCD displays with tiled bezel widths of 1.8 or 3.5mm and 500 or 700-nit brightness. The Planar VM Series delivers high reliability to meet the demands of digital signage applications including retail, hospitality, universities, sports bars, corporate lobbies, casinos and museums.

High Performance

  • IPS technology provides outstanding viewing angles and contrast
  • 4K@60Hz DisplayPort and HDMI connectivity including HDCP 2.2
  • 24x7 operation and reliability to support extended use
  • Source failover to ensure continuous on-screen activity without downtime
  • Fanless display

Video Wall Versatility

  • 55" displays available in landscape or portrait orientation
  • OPS (Open Pluggable Specification) slot enables seamless integration of compatible digital signage hardware
  • Multiple brightness options of 700-nit (MX models) and 500-nit (LX models) to optimize viewing in different ambient light environments

Optimized for Tiled Installations

  • Tiled bezel widths as small as 1.8mm
  • Built-in video wall scaling to supports up to 10x10 display configurations
  • VESA mounting compatibility
  • Multiple daisy-chain signal support (DisplayPort, HDMI, DVI, and VGA)

Backlight Technology LED
Bezel Width 35.4 mil
Bezel Width (Bottom) 35.4 mil
Brand Name Planar
Brightness 500 Nit
Category Type Retail & Hospitality, House of Worship, Education, Corporate & Telework, Videowall Displays
Color Black
Color Depth 10-bit
Color Gamut 72% NTSC
Depth 3.9", 26.9"
Display Resolution 1920 x 1080
Display Screen Type LCD, LED
Dynamic Contrast Ratio 20,000:1
Environmental Certification cTUVus
Environmentally Friendly Yes
Ethernet Yes
HDMI Yes
Height 26.9"
Input Voltage 120 V AC, 230 V AC, 120 V AC, 230 V AC
Limited Warranty 3 Year
Manufacturer Leyard
Model 997-9219-00
Maximum Video Resolution 1920 x 1080
Minimum Screen Size Supported 55"
Number of +12V Rails 2
Number of DisplayPorts 2
Number of HDMI Inputs 2
Number of HDMI Outputs 1
Number of USB 2.0 Ports 2
Number of USB 3.0 Ports 1
Packaged Quantity 1
Pixel Pitch 24.8 mil
Product Series VM
Product Type Digital Signage Display
Scan Format 1080p
Screen Size 55"
Serial Yes
USB Yes
Vendor Name Planar
Video Wall Compatible Yes
Weight (Approximate) 53.80 lb
Width 3.9", 47.7"
