Panamax MR4300 Line Conditioner
Panamax MR4300 Line Conditioner

Panamax MR4300 Line Conditioner

Model: MR4300

Category: AV Power

Brand: Panamax

Dealer pricing

Panamax's MR Family of products offers several layers of surge protection. Panamax's patented Automatic Voltage Monitoring (AVM) technology continuously monitors the incoming power. In case of an undervoltage or brownout (too little electricity) or an overvoltage (too much electricity) a flashing red lightning bolt will be displayed and power to the equipment is automatically turned off. When voltage returns to a safe level, power to the equipment is automatically reconnected.

The other layer of surge protection Panamax offers is our exclusive Protect or Disconnect™ technology. This ultra fast protection circuitry completely protects your equipment from surges such as lightning. When overwhelmed with extreme catastrophic events, Panamax permanently disconnects AC power to equipment. All Panamax products offer this core protection technology.

Main Features

  • 9 Protected & Filtered Power outlets
  • Exclusive Automatic Voltage Monitoring (AVM)
  • Protect or Disconnect™ Technology
  • USB Charging (0.5V/5V)
  • Linear Level 3 Filtration (2 Total Isolated banks) with Dedicated High Current Outlet Bank (4 Outlets)
  • Antenna, Cable, or Satellite, LAN and TELCO signal protection
  • Rotating & Dimmable Media Lights Illuminate Equipment
  • 8 ft. Power Cable with Low Profile Plug
  • Rack ears included

Brand Name Panamax
Cable Length 8 ft
Cord Length 8 ft
Depth 2.2", 6"
Form Factor External
Frequency 60 Hz
Height 6", 2.2"
Input Voltage 120 V AC, 110 V AC
Limited Warranty 3 Year
Load Capacity (Watt) 1800 W
Model MR4300
Maximum Frequency 60 Hz
Maximum Line Current 3 kA
Output Voltage 120 V AC
Power Rating 1800 W
Product Series MR
Product Type Line Conditioner
Protection Type Line to Neutral, Lightning, Neutral to Ground, AC Noise, AC Surge, Brownout, Lightning, Line to Neutral, Neutral to Ground, Over Voltage, Under Voltage, AC Surge, Brownout, Over Voltage, Under Voltage, AC Noise
Receptacle Detail 9 x AC Power
Receptacle Type USB, F Connector, RJ-11, RJ-45, AC Power, AC Power, F Connector, RJ-11, RJ-45, USB
Receptacles Detail 9 x AC Power
Surge Energy Rating 1575 J
Vendor Name Panamax
Weight (Approximate) 6.50 lb
Width 17"
