CONTROL PANEL, 120V, BACNET MS/TP OUTPUT,12 ANALOG
CONTROL PANEL, 120V, BACNET MS/TP OUTPUT,12 ANALOG

CONTROL PANEL, 120V, BACNET MS/TP OUTPUT,12 ANALOG

Model: 70-2900-0402-3

Category: Conventional Fire Panels

Brand: Macurco (aerionics)

Dealer pricing

Detection Ventilation Control Panels

The Macurco controller family has a variety of options to meet the needs of your facility. These controllers in conjunction with Macurco gas detectors provide automatic control to help maintain an acceptable environment in parking garages or other applications. These systems are easily configured making installation hassle-free. The control panel series is designed to meet specifications for safety in enclosed parking garages, including the Uniform Building Code and OSHA 50ppm CO requirements. With mutiple control panel options Macurco will help you find the right controller for your specific application.

Key Features

  • 12 analog (4-20mA) sensor connections
  • DVP-120M/B : 87 digital sensor connections (RS-485) + 12 analog (4-20mA) sensor connections
  • Three 10A SPDT fan / alarm relays
  • Two 24VDC drivers for Horn / Strobe
  • Compatible with Macurco 6-Series
  • Auto recognizes Macurco detectors
  • Settings are customizable, default is per OSHA
  • DVP-120B : BACnet MSTP output

ADI Part Number MA-DVP120B
Brand Name Macurco
Category Type Conventional Fire Panels
Display Screen Type LCD
Features Built-in Keypad
Input Voltage 120 V AC, 230 V AC
Limited Warranty 2 Year
Manufacturer Aerionics, Inc
Model 70-2900-0402-3
Packaged Quantity 3
Product Type Gas Alarm Control Panel
Vendor Name Macurco (aerionics)
Weight (Approximate) 6.50 lb
