Model: AE-100

Category: Door Entry, Telephone Entry

Brand: Linear

Dealer pricing

The Model AE-100 Commercial Telephone Entry System - One Door is designed for use as a primary access control device for apartments, condominiums, and offices with up to 125 residents. The system can be used in a lobby or outside. Surface, recessed, and pedestal mounting options are supported. The system utilizes hands-free, full duplex telephone communications between visitors and residents for granting access.

Main Features

  • Installation choices: surface mount, recessed, gooseneck
  • Stainless steel front panel
  • Telephone style keypad with lighting
  • Accepts a total of 125 directory listings or stand-alone entry codes
  • TTY jack for connection to text communication for the hearing impaired
  • Simple network capability with up to four units – allows transferring programming data from “master” unit to other sub-units
  • Two-line-16-character LCD display
  • Removable terminal blocks
  • Form “C” access relay rated at 10 amps AC and 7 amps DC @ 30 volts
  • Load shed circuitry protects backup battery
  • Dimensions: 9.75″ W x 11.75″ H x 3.5″ D

Application/Usage Access Control, Apartment, Building, Condominium, Gated Community, Lobby, Office, Outdoor
Brand Name Linear PRO Access
Category Type Telephone Entry
Connectivity Technology Cable
Depth 3.5"
Form Factor Goose-neck Mount, Pedestal Mount, Recessed Mount, Surface Mount
Height 9.8", 11.8"
Input Voltage 16 V AC
Manufacturer Nice S.p.A., Nortek Security & Control LLC
Model AE-100
Material Stainless Steel
Number Of Sensors Included 125
Polarization Linear
Power Source AC Supply, Battery
Product Type Telephone Entry System, Intercom Sub Station
Vendor Name Linear
Width 9.8"
