Inovonics EchoStream EN4204R Zone Expansion Module
Inovonics EchoStream EN4204R Zone Expansion Module

Inovonics EchoStream EN4204R Zone Expansion Module

Model: EN4204R

Category: Wireless Alarm Systems, Wireless Intrusion Receivers & Repeaters

Brand: Inovonics

Dealer pricing

The Inovonics four zone add-on receiver with relay outputs programs and supervises up to four Inovonics transmitters. This receiver includes Form C relays for each output, allowing connection to any hardwire panel, or stand-alone wireless application.

Main Features
  • Add up to four high performance EchoStream wireless transmitters to any installation
  • LED allows the user to view the current status of all four transmitters
  • Five form C relays for connecting to any panel: four alarm, one fault
  • Outputs can be configured in follower, latching, momentary, or toggle modes independently
  • Case tamper protection, jam detection, and internal antennas for a secure wireless implementation
  • Wireless programming routine built into the receiver
  • Power requirement: 11 - 14 VDC; 400 mA
  • Output specifications: Form C relay 1A @ 28 VDC, 0.5A @ 30 VAC resistive load; N/O receiver case tamper contact closure, N/C receiver jam output indication
  • Input specifications: A low is less than .5 V; a high is greater than 2.5 V
  • EchoStream® frequency: 902-928 MHz, frequency hopping spread spectrum

Brand Name Inovonics
Category Type Wireless Intrusion Receivers & Repeaters
Limited Warranty 3 Year
Manufacturer Inovonics Wireless Corporation
Model EN4204R
Product Line EchoStream
Product Type Zone Interface/Expansion Module
Vendor Name Inovonics
