Hochiki FN-1024-ULX-R Remote Power Extender
Hochiki FN-1024-ULX-R Remote Power Extender

Hochiki FN-1024-ULX-R Remote Power Extender

Model: 0500-02310 / FN-1024ULX-R

Category: Power Supplies, Batteries & Power Supplies

Brand: Hochiki

Dealer pricing

The FN-300-ULX, FN-400-ULX, FN-600-ULX, and FN-1024-ULX are extremely cost effective voltage regulated remote Power Extenders. These power supply/ charger s convert a 115VAC / 60Hz input, to a 12VDC or 24VDC regulated output. The ULX series Power Extenders are designed to provide auxiliary power to support system accessories.

Features

  • Input fuse rated @ 3.5 amps/250V
  • Filtered and electronically regulated output
  • Short circuit and thermal overload protection
  • AC fail supervision (form “C” contacts)
  • Low battery supervision (form “C” contacts)
  • Battery presence supervision (form “C” contacts) • Built-in charger for sealed lead acid or gel type batteries
  • Automatic switch over to stand-by battery when AC fails
  • Zero voltage drop when switched over to battery backup
  • AC input and DC output LED indicators
  • Accommodates up to two (2) 12VDC/7AH batteries
  • Power supply, enclosure, cam lock and battery leads

ADI Part Number HY-1024ULXR
Brand Name Hochiki
Model 0500-02310 / FN-1024ULX-R
Vendor Name Hochiki
