Hikvision Embedded Plug & Play 4K NVR

Model: DS-7716NI-I4/16P-2TB

Category: Recording Devices, NVRs

Brand: Hikvision

Dealer pricing

The DS-7716NI-I4/16P NVR provides high resolution, high video compression, VGA and CVBS output, and HDMI video output up to 4K. 16 independent PoE connections offer easy setup, and smart search and smart playback make locating specific incidents quick and accurate. The dual-OS design ensures high system reliability, and Hikvision’s proprietary ANR technology guarantees storage reliability when the network is disconnected.

The DS-7716NI-I4/16P supports live view, recording, and storage of up to 16 cameras simultaneously, with resolutions up to 12 MP. Customers will benefit from the centralized management of cameras and features such as information import/export, real-time information display, two-way audio, and VCA detection alarms

Main features

  • Up to 12 MP Resolution
  • 16 IP Camera Inputs, 160 Mbps Bandwidth
  • H.265+/H.265/H.264+/H.264/MPEG4 Compression
  • HDMI Video Output Up to 4K (3840 × 2160)
  • 16 Independent PoE Network Interface Camera Connections
  • Long Distance (100 to 300 m) Network Transmission via PoE
  • Independent HDMI, VGA and CVBS Outputs
  • 4x (10 TB) SATA HDD, DVD-RW Option
  • Smart Search and Smart Playback
  • Alarm and Audio I/O

Brand Name Hikvision
Category Type NVRs
Composite Video In Yes
Connectivity Technology Wired
Depth 2.8", 15.4", 17.5"
Environmentally Friendly Yes
Ethernet Yes
Hard Drive 2 TB
Hard Drive Capacity 2 TB
HD Recording Yes
HDMI Yes
Height 2.8"
Limited Warranty 3 Year
Manufacturer Hikvision
Model DS-7716NI-I4/16P-2TB
Maximum Load Capacity 11.02 lb
Maximum Resolution 1920 x 1080
Maximum Video Resolution 1920 x 1080
Number of PoE+ (RJ-45) Ports 16
Number of VGA Out 1
Packaged Quantity 1
Product Series 7700
Product Type Video Surveillance Station
Remote Management Yes
System Components Network Video Recorder
Total Number of Audio In Ports 1
Total Number of Audio Out Ports 1
Total Number of Channels 16
USB Yes
Vendor Name Hikvision
Video Formats H.264, H.264+, H.265, MPEG-4, MPEG-4, H.265, H.264+, H.264
Weight (Approximate) 11.02 lb
Width 15.4", 17.5"
