Functional Devices RIB21CDC-RD Relay
Functional Devices RIB21CDC-RD Relay

Functional Devices RIB21CDC-RD Relay

Model: RIB21CDC-RD

Category: Power Products, Surge Protection & PDUs

Brand: Functional Devices

Dealer pricing

Enclosed Relay 10 Amp SPDT, Class 2 Dry Contact Input, 120-277 Vac Power Input, Red Housing

Main Features
  • Relays & Contact Type: One (1) SPDT Continuous Duty Coil
  • Expected Relay Life: 10 million cycles minimum mechanical
  • Operating Temperature: -30 to 140° F
  • Humidity Range: 5 to 95% (noncondensing)
  • Operate Time: 1.8 Seconds
  • Relay Status: LED On = Activated
  • Dimensions: 1.70? x 2.80? x 1.50? with .50? NPT Nipple
  • Wires: 16?, 600V Rated
  • Approvals: UL Listed, UL916, C-UL, CE, RoHS
  • Housing Rating: UL Accepted for Use in Plenum, NEMA 1

Application/Usage Pilot
Brand Name Functional Devices
Category Type Surge Protection & PDUs
Color Red
Depth 1.7", 2.8", 1.5"
Environmental Certification RoHS
Environmentally Friendly Yes
Height 1.7"
Limited Warranty 1 Year
Manufacturer Functional Devices, Inc
Model RIB21CDC-RD
Product Type Relay
Vendor Name Functional Devices
Width 1.5", 2.8"
