Dahua 4K Penta-brid HDCVI DVR
Dahua 4K Penta-brid HDCVI DVR

Dahua 4K Penta-brid HDCVI DVR

Model: X72A3A

Category: HDoC DVRs

Brand: Dahua Technology

Dealer pricing

The X72A Series HDCVI DVR offers 4K recording on each HDCVI channel and a host of advanced features and functions. The X72A takes advantage of HDCVI technology for easy integration into existing video surveillance systems while leveraging existing networks, cabling, and cameras. Penta-brid access technology seamlessly records video from HDCVI, AHD, TVI, CVBS, and IP sources simultaneously at 4K resolution on each channel.

The X72A utilizes the Smart H.265+ Codec to significantly improve encoding efficiency and to reduce bandwidth and storage costs. In addition to the advanced codec, the X72A series supports Internet of Things (IoT) functionality and Point of Sale (PoS) integration. This recorder is the ideal solution for actively monitoring and recording video feeds in a wide range of applications including public venues, retail stores, transportation hubs and access ways, personal property and homes, and educational institutions.

Main Features
  • 4K at 7 fps Recording Resolution on All HDCVI Channels
  • Dual-stream Video Recording
  • Smart H.265+ and H.264 Dual Codec
  • Auto-detection and Auto-configuration of Video Inputs
  • 16 + 16 IP Camera Channels, each channel up to 8 MP
  • Maximum 128 Mbps Incoming Bandwidth
  • Smart Search and Intelligent Video System
  • Spot Output
  • Five-year Warranty (for products sold through an authorized Dahua dealer)

Brand Name Dahua
Category Type HDoC DVRs
Composite Video In Yes
Connectivity Technology Wired
Depth 11.3", 14.8"
Environmentally Friendly Yes
Ethernet Yes
Frame Rate 60 Frames Per Second
Graphics Modes 4K
HD Recording Yes
HDMI Yes
Height 2.1"
Limited Warranty 3 Year
Manufacturer Zhejiang Dahua Technology Co., Ltd.
Model X72A3A
Maximum Frame Rate 60 fps
Maximum Resolution 4K
Number of VGA Out 1
Packaged Quantity 4, 1
Product Series Pro
Product Type Video Surveillance Station
Remote Management Yes
System Components Hybrid Video Recorder
Threads Per Inch (TPI) 32
Total Number of Audio In Ports 4
Total Number of Audio Out Ports 1
Total Number of Channels 32
USB Yes
Vendor Name Dahua Technology
Video Formats H.264, H.264+, H.265, H.265+, H.265+, H.265, H.264+, H.264
Video Signal Format NTSC
Weight (Approximate) 3.97 lb
Width 14.8", 2.1"
