Model: NDE-8504-R
Category: IP PTZ Cameras
Brand: Bosch
Dealer pricingsurveillance/network cameras bosch nde-8504-r 1058804211 6lg450 46171610 800549819459 13672225 5521847 0800549819459 6391487 pb-nde8504r s bosch flexidome ip nde-8504-r 8 megapixel network camera dome h.265 h.264 mjpeg 3840 2160 2.6x optical cmos FLEXIDOME IP 8000i Starlight VCA FLEXIDOME IP 8000i Network Camera NDE-8504-R NDAA Compliant
| Antenna Type | Dome |
| Brand Name | Bosch |
| Category Type | IP PTZ Cameras |
| Color | White |
| Color Supported | Color, Monochrome, Monochrome, Color |
| Connectivity Technology | Wired |
| Depth | 5.8" |
| Durability | Dust Resistant, Impact Resistant, Rain Resistant, Snow Resistant, Water Resistant, Wind Resistance |
| Effective Camera Resolution | 8 Megapixel |
| Environmental Certification | China RoHS, REACH, WEEE |
| Environmentally Friendly | Yes |
| Features | Auto Tracking, Automatic Defog, Automatic White Balance, Cross Line Detection, Day/Night, Dynamic Noise Reduction, Enter/Exit Detector, Region of Interest, SD Card Local Storage, Tamper Detection, Wide Dynamic Range |
| Field of View | Wide: 36.2º x 19.9º (H x V); Tele: 12.6º x 7.1º (H x V) |
| Form Factor | Dome |
| Graphics Modes | 4K |
| HD Recording | Yes |
| Height | 6.9" |
| Image Sensor | CMOS |
| Image Sensor Type | CMOS |
| Impact Protection Rating | IK10, IK10+ |
| Ingress Protection Rating | IP66, IP6K9K |
| Input Voltage | 24 V AC, 24 V AC, 26 V DC |
| Lens Type | Varifocal, Zoom |
| Longest Shutter Speed | 1/30 Second |
| Manufacturer | The Bosch Group |
| Model | NDE-8504-R |
| Maximum Aperture | f/2.7, f/1.6 |
| Maximum Focal Length | 10 mm |
| Maximum Frame Rate | 30 fps |
| Maximum Operating Temperature | 165.2°F (74°C) |
| Maximum Video Resolution | 3840 x 2160 |
| Minimum Focal Length | 3.90 mm |
| Mount Type | Ceiling Mount, In-ceiling, Parapet Mount, Pendant Mount, Pipe Mount, Pole Mount, Surface Mount, Wall Mount |
| Network (RJ-45) | Yes |
| Operating Humidity | 100% |
| Optical Zoom | 2.6x, 3.3x |
| Packaged Quantity | 1 |
| Product Line | FLEXIDOME IP |
| Product Series | HD, 8000i |
| Product Type | Network Camera |
| Shortest Shutter Speed | 1/15000 Second |
| Storage Type | Memory Card |
| Temperature Range | -58°F (-50°C) |
| Vendor Name | Bosch |
| Video Formats | H.264, H.265, MJPEG, H.265, MJPEG, H.264 |
| Weight (Approximate) | 5.07 lb |
