Bogen UDR800 800-Channel PLL-Synthesized UHF Receiver

Model: UDR800

Category: Handheld Wired Mics

Brand: Bogen Communcations

Dealer pricing

Offers 800 user-selectable frequencies in UHF 470-490 MHz band; 120 dB dynamic range; operation up to 500 feet line-of-sight
DigiTRU Diversity™ for maximum range and dropout protection, full LED indicators, 1/4" unbalanced and XLR balanced outputs, Tone Squelch™ for locking out potential interference, noiseless transmitter ON/OFF switching, & level control for unbalanced output
Half-rack receiver design with front panel dual antennas, powered by wall power adapter
8" W x 1-5/8" H x 5-1/8" D; antenna 2-3/4"; 1 lb.

6.35mm (?1?4")	Yes
6.35mm (?1/4")	Yes
Brand Name	Bogen
Category Type	Corporate & Telework, Education, House of Worship, Retail & Hospitality, Handheld Wired Mics
Depth	5.1"
Height	1.6"
Input Voltage	22 V DC
Model	UDR800
Maximum Frequency Response	18 kHz
Maximum Operating Frequency	490 MHz
Minimum Frequency Response	50 Hz
Minimum Operating Frequency	470 MHz
Operating Range	500 ft
Vendor Name	Bogen Communcations
Weight (Approximate)	1 lb
Width	8"
XLR	Yes
