AXIS T8120 Midspan 15 W 1-Port
AXIS T8120 Midspan 15 W 1-Port

AXIS T8120 Midspan 15 W 1-Port

Model: 5026-204

Category: POE Midspans, Injectors & Repeaters

Brand: Axis Communications Inc

Dealer pricing

Power over Ethernet (PoE) offers an easy, fast and cost-effective solution for supplying power to network video products without the need to install power outlets and electrical cabling. Simply connect the Axis PoE midspans and PoE splitters to the network, and the network video products are supplied with power.

Axis PoE midspans provide power (max. 15.4 W per port) over Ethernet cables to network video products with built-in PoE support. For a network video product without built-in PoE support, a PoE splitter must be used to separate power and data coming over the network cable.

Main Features

  • Input Voltage: 110 V AC, 220 V AC
  • Maximum Output Voltage: 48 V DC
  • Maximum Output Power: 15.40 W
  • Output Ports: 1
  • Mount Type: Wall Mountable
  • Height: 1.2"
  • Width: 2.4"
  • Depth: 5.7"
  • Weight (Approximate): 15.87 oz
  • Compatibility: Video EncodersAxis Network Cameras:, PTZ, PTZ Dome
  • Certifications & Standards: IEEE 802.3, IEEE 802.3af, FCC Part 15 Class B, EN55022 (CISPR 22) Class BSafety:, cUL, UL, TUV, CE

Brand Name AXIS
Depth 5.7", 1.2"
Form Factor Wall Mountable
Height 5.7", 1.2"
Input Voltage 220 V AC, 110 V AC, 220 V AC, 110 V AC, 48 V DC
Limited Warranty 3 Year
Manufacturer Axis Communications
Model 5026-204
Maximum Frequency 63 Hz
Maximum Output Current 500 mA
Maximum Output Power 15.40 W
Maximum Output Voltage 48 V DC
Minimum Frequency 47 Hz
Minimum Input Current 500 mA
Mount Type Wall Mountable
Output Ports 1
Packaged Quantity 1
Product Type PoE Injector
Vendor Name Axis Communications Inc
Weight (Approximate) 15.87 oz
Width 2.4"
