AVYCON ALL-IN-ONE Network Tester
AVYCON ALL-IN-ONE Network Tester

AVYCON ALL-IN-ONE Network Tester

Model: AIVO-40T4KP

Category: Test Equipment, Camera Test Equipment

Brand: Avycon

Dealer pricing

The AIVO-40T4KP from Avycon is a 4.0" HD-TVI network wristband tester.

Main Features

  • 4" High Definition Touch Screen, 800 x 480 resolution
  • H.265, H.264, up to 4K video display via IPC Mainstream
  • 4K Video files and MKV / MP4 formats supported for playback
  • 8MP (4K) TVI test, supports up to 3840 x 2160P @ 15FPS
  • 8MP AHD test, 3840 x 2160P @ 15FPS
  • 8MP CVI test, 3840 x 2160P @ 15FPS
  • Up to 4 Channels Rapid Onvif scan, Auto login, View live video, and create camera test reports
  • ONVIF PTZ Contol, Video Record and Playback, Screen Snapshot, 4x Digital Zoom,
  • Move the image display and Video Output
  • Testerplay™ - Display camera stream on tester and PC/Mobile Devices simultaneously

Battery Built-in Yes
Battery Chemistry Lithium Polymer (Li-Polymer)
Battery Rechargeable Yes
Battery Size Supported 7.4V
Brand Name AVYCON
Category Type Camera Test Equipment
Depth 1.3"
Device Function PTZ Control, Audio Signal Testing, BNC Cable Testing, Cable Testing, Camera Testing, Fiber Optic Cable Testing, IP Camera Testing, Network Testing, PoE Testing, PTZ Control, Video Level Meter, BNC Cable Testing, Video Level Meter, Audio Signal Testing, Fiber Optic Cable Testing, IP Camera Testing, Camera Testing, PoE Testing, Network Testing, Cable Testing
Environmentally Friendly Yes
Ethernet Technology Fast Ethernet
Height 5"
Input Voltage 12 V DC
Model AIVO-40T4KP
Maximum Operating Range 5"
Media Type Supported Twisted Pair
More Ways To Save Hot Deals
Network (RJ-45) Yes
Network Standard 10/100Base-T
Network Technology 10/100Base-T
PoE (RJ-45) Port Yes
Product Type Network Testing Device
Vendor Name Avycon
Weight (Approximate) 11.29 oz
Width 1.3", 3.3"
Wireless LAN Yes
