APC Back-UPS CS 500VA
APC Back-UPS CS 500VA

APC Back-UPS CS 500VA

Model: BK500

Category: Uninterrupted Power Supplies

Brand: Apc - American Power Conversio

Dealer pricing

Protect your electronics with this 6-outlet, 120-volt battery backup system. 300-watt back-UPS features a surge energy rating of 480 joules. Serial connection lets you use your PC to access additional power protection and management features for your uninterruptible power supply (UPS) through a serial port. Disconnected battery notification warns you when a battery is not available to provide backup power. Cold-start capability provides temporary battery power when the utility power is out. Dataline surge protection protects connected equipment from power surges on the data lines. Hot-swappable batteries ensure clean, uninterrupted power to your protected equipment while the batteries are being replaced. Wiring fault indicator informs you of potentially dangerous wiring problems in the wall circuit.

Main Features
  • Building Wiring Fault Indicator

    This LED informs users of potentially dangerous wiring problems in the wall circuit.

  • Cold-start capable

    Provides temporary battery power when the utility power is out.

  • Dataline surge protection

    Provides protection of connected equipment from power surges on the data lines.

  • Disconnected battery notification

    Warns when a battery is not available to provide backup power.

  • Hot-swappable batteries

    Ensures clean, uninterrupted power to protected equipment while batteries are being replaced

  • Lifetime data recovery warranty

    Provides peace of mind by providing professional data recovery services in the event data is lost due to the failure of the unit.

  • Serial connection

    Use your PC to access additional power protection and management features for your UPS via a serial port.

  • Simple battery replacement

    Increases UPS availability by allowing quick, easy battery replacement.

  • Transformer-block spaced outlets

    Protect equipment with input transformer blocks without blocking access to other receptacles.

  • USB connection

    Use your PC to access additional power protection and management features for your UPS via a USB Port.

Additional Warranty Information

3 years warranty
Alarm Overload, On Battery, Low Battery
Alarm Low Battery, On Battery, Overload
Assembly Required No
Backup/Run Time (Full Load) 3 Minute
Backup/Run Time (Half Load) 15 Minute
Backup/Run Time (With Optional Battery) 8 Hour
Battery Characteristics Spill-proof, Maintenance-free
Battery Chemistry Sealed Lead Acid (SLA)
Brand Name Dell EMC, APC by Schneider Electric
Category Type Uninterrupted Power Supplies
Color Beige
Cord Length 6 ft
Dataline Protection RJ-11
Depth 11.2"
Energy Star Yes
Environmental Certification ENERGY STAR
Environmentally Friendly Yes
Form Factor Tower
Height 3.6", 6.5"
Input Voltage 110 V AC, 120 V AC
Limited Warranty 3 Year
Load Capacity 500 VA
Manufacturer Schneider Electric SA
Model BK500
Maximum Operating Temperature 113°F (45°C), 113°F (45°C)
Output Voltage 120 V AC
Packaged Quantity 1 Each
Plug/Connector Type NEMA 5-15P
PMPO Output Power 300 W
Power Consumption 300 W
Product Line Back-UPS
Product Series CS
Product Type Line-interactive UPS
Receptacle Detail 3 x NEMA 5-15R
Receptacle Type NEMA 5-15R
Recycled No
Serial Port Yes
Sound Emission 45 dB(A)
Status Indicators LED status display with On Line, On Battery, Replace Battery, Site wiring Fault and Overload indicators
Surge Energy Rating 480 J
Thermal Dissipation 7.03 W
Typical Battery Recharge Time 8 Hour
USB Yes
Vendor Name Apc - American Power Conversio
Waveform Type Step Wave, Stepped Sine Wave
Weight (Approximate) 13.80 lb
Width 3.6"
