AMX Conferencing Connectivity and Transport Kit

Model: FG1010-910

Category: Presentation Systems & Scalers

Brand: Amx By Harman

Dealer pricing

The AMX Connectivity and Transport (CT) Series is a family of 4K switching and distribution kits that combine switching, scaling and distance transport into a single kit that includes both a transmitter and receiver. The solutions deliver added value and flexibility to conferencing and presentation solutions by providing a single, simple to implement solution that offers switching and connectivity where you need it along with unified control of both the transmitter and receiver - all over a single category cable. Solutions available include a Presentation kit, targeting simple presentation environments, and a Conferencing kit, targeting web conferencing applications.

The CT Conferencing kit combines multi - format 4K60 video switching, scaling, and distance transport with USB 2.0 peripheral switching. This allows dynamic sharing of room USB peripherals between visiting laptops, etc., and permanently installed devices such as an Acendo Core or room PC. This ensures excellent sound and visuals for guests whether they are using installed equipment or bringing their own devices - at a cost effective price.

Main Features

  • 4K60 4:4:4 Support-Future proof for 4K source devices and displays
  • HDMI, DP,VGA, and USB-C Inputs (TX)-Supports common laptop video connectors at the table
  • HDMI Inputs (RX)-Switch to devices such as Acendo Core or a room PC located near the display
  • USB 2.0-Allows room USB devices at the table or near the display to be dynamically shared between visiting and permanent computing devices without having to disconnect/reconnect
  • Simplified Room Control-Control the display or projector and a screen from built-in control ports on the RX.
  • Ideal for web conferencing solutions with cameras, mics and other USB devices installed .

ADI Part Number AI-FG1010910
Brand Name AMX
Category Type Retail & Hospitality, House of Worship, Presentation Systems & Scalers, Education, Corporate & Telework
Connectivity Technology Wired
DisplayPort Yes
Environmentally Friendly Yes
Form Factor Rack-mountable
Graphics Modes 4K
HDMI In Yes
HDMI Out Yes
Lock Height 1.65"
Lock Length 8.66"
Manufacturer Harman International Industries, Inc
Model FG1010-910
Maximum Distance Supported 328.08 ft
Maximum Operating Distance 328.08 ft
Maximum Video Resolution 4096 x 2160
Media Type Supported Twisted Pair
Network (RJ-45) Yes
Number of HDMI Inputs 3
Number of HDMI Outputs 1
Number of Input Devices Supported 4
Number of Network (RJ-45) Ports 6
Number of Output Devices Supported 1
Number of USB Ports 11
Number of VGA Inputs 1
Packaged Quantity 1, 3, 4
Product Series 6
Product Type Video Extender Transmitter/Receiver
Serial Port Yes
Shipping Depth 5.90"
Total Number of Network Ports 11
Transmitter Depth 5.90"
Transmitter Height 1.65"
Transmitter Weight (Approximate) 4.21 lb
Transmitter Width 8.66"
Twisted Pair Cable Standard Category 7
USB Yes
Vendor Name Amx By Harman
VGA In Yes
